Balancing Valve
Body: Cast Iron, Ductile Iron
Disc: Ductile Iron, SS304, SS316, Bronze
Shaft: SS410, SS431
Seat Ring: EPDM, NBR
O-Ring: EPDM, NBR
Bushing: PTFE, Bronze
Nominal Diameter: DN50 to DN150
Nominal Pressure: Class150, PN16
Design and manufacturing: DIN EN 13709, DIN 3356
Flanged End Dimensions: EN1092-1 PN25
Face to face Dimensions: EN558-1
Inspection and Test: EN 12266-1
Dimensions Unit: mm
DN | L | H |
50 | 230 | 260 |
65 | 290 | 290 |
80 | 310 | 310 |
100 | 350 | 325 |
125 | 400 | 355 |
150 | 480 | 390 |
