Dual Plate Lug Check Valve

Dual Plate Lug Check Valve

Middleeast is a fast growing and renowned dual plate lug check valve supplier in Oman . A dual plate lug check valve is a type of non-return valve that is designed to prevent the backflow of fluid in a pipeline. It consists of two spring-loaded plates that are mounted on lugs, which are located on the sides of the valve body. The plates pivot around the lugs and seal against the valve body to prevent backflow. When fluid flows through the valve in the proper direction, the plates are forced open, allowing the fluid to pass through. When the flow stops or reverses, the spring-loaded plates close, preventing backflow. Dual plate lug check valves are commonly used in industrial and commercial applications such as water treatment plants, oil and gas pipelines, and power plants. An actuator is an optional component that can be added to a dual plate lug check valve to allow for remote operation or automatic control. The actuator is connected to the valve body and is used to open and close the valve.

There are different types of actuators that can be used with a dual plate lug check valve, including: Pneumatic actuator, Electric actuator, Hydraulic actuator.

Middleeast is the largest dual plate lug check valve supplier in Oman. While manufacturing, we keep in mind the industrial standards and maintain the quality standards of the valves.

Parts

• Body
• Plates
• Hinge
• Spring
• Seats
• Seal
• Actuator
• Bonnet

Advantages

• The valve is Bi-directional
• It is compact and lightweight
• It has low pressure drop
• The valve closes quickly, which helps prevent backflow and potential damage to the pipeline or equipment.
• The valve is relatively simple to maintain and can be disassembled and reassembled easily for cleaning or repair.
• These valves can be used in a wide range of applications such as water supply systems, industrial piping systems, and chemical and petrochemical plants.
• Due to its simple design, the valve is relatively inexpensive to manufacture and purchase.
• If actuator is added, it offers remote operation and automatic control, which gives better control over the flow of fluid.
• The valve is made of durable materials and can withstand high pressure and temperatures, making it suitable for use in harsh environments.

Industries which use them

• Water Treatment Plants
• Oil and gas Industry
• Power Generation Plants
• Pharmaceutical Industries
• Chemical and Petrochemical Industries
• Marine Industry
• Pulp and paper Industry

Applications

• Dual plate lug check valves are commonly used in water supply systems to control the flow of water in pipelines and prevent backflow.
• These valves are used in industrial piping systems to control the flow of liquids, gases, and other materials in pipelines and prevent backflow.
• These valves are used in fire protection systems to prevent the backflow of water in the event of a fire.
• These valves are used in sewage systems to control the flow of sewage and prevent backflow.
• These valves are used in irrigation systems to control the flow of water in pipelines and prevent backflow.
• They are used in the oil and gas industry to control the flow of oil, gas, and other fluids in pipelines, storage tanks, and other equipment.
• They are used in power generation plants to control the flow of steam, water, and other fluids in pipelines and other equipment.
• Are used in the pharmaceutical industry to control the flow of liquids, gases, and other materials in pipelines and other equipment.
• The valves are used in chemical and petrochemical plants to control the flow of chemicals, gases, and other materials in pipelines and other equipment.
